- General Information
- Manufacturer
- Acer, Inc
- Manufacturer Website Address
- http://www.acer.co.uk
- Brand Name
- Acer
- Product Line
- Vero
- Product Type
- DLP Projector
- Warranty
- Additional Warranty Information
- EMEA Warranty
- Technical Information
- Projection Method
- Front Ceiling
- Rear
- Front
- Rear Ceiling
- 3D Type
- 3D
- Platform Supported
- Mac
- PC
- AI-powered
- Yes
- Projection System
- DLP
- 3D Capability
- DLP 3D
- Video Compatibility
- SDTV
- HDTV
- NTSC
- EDTV
- SECAM
- PAL
- Projection Offset (Half-Height)
- 132%
- Fan Noise (Economy Mode)
- 26 dB
- Display & Graphics
- Native Resolution
- 1920 x 1080
- Maximum Resolution
- 3840 x 2160
- Native Aspect Ratio
- 16:9
- Graphic Mode
- 4K2K
- Projection Lens
- Lens Type
- Manual Zoom
- Manual Focus
- Minimum Focal Length
- 16.90 mm
- Maximum Focal Length
- 21.61 mm
- Minimum Diagonal Image Size
- 787.40 mm
- Maximum Diagonal Image Size
- 7.62 m (300")
- Optical Zoom
- 1.3x
- Minimum Lens Aperture
- f/2.43
- Maximum Lens Aperture
- f/2.78
- Minimum Projection Distance
- 1 m
- Maximum Projection Distance
- 7.50 m
- Lamp
- Number of Lamps
- 1
- Lamp Type
- Laser Diode
- Lamp Power
- 66 W
- Normal Mode Lamp Life
- 20000 Hour
- Economy Mode Lamp Life
- 30000 Hour
- Image
- Low Mode Brightness
- 3420 lm
- Standard Mode Brightness
- 5500 lm
- Standard Mode Brightness Disclaimer
- Compliant with ISO 21118 standard
- Colour Supported
- 1.07 Billion Colors
- Compatible Aspect Ratio
- 4:3
- Throw Ratio
- 1.12 to 1.47 (2057.40 mm@2000 mm)
- Zoom Ratio
- 1.3:1
- Contrast Ratio
- 50,000:1
- Uniformity
- 75%
- Vertical Keystone Correction
- -40°/+40°
- Minimum Vertical Sync
- 24 Hz
- Maximum Vertical Sync
- 120 Hz
- Minimum Horizontal Sync
- 15 kHz
- Maximum Horizontal Sync
- 135 kHz
- Digital Zoom
- 2x
- Video
- Video Signal Format
- NTSC 3.58
- NTSC 4.43
- PAL B
- PAL D
- PAL G
- PAL I
- PAL M
- PAL N
- SECAM B
- SECAM D
- SECAM G
- SECAM K
- SECAM K1
- SECAM L
- Video Signal Standard
- HDTV
- Input Scan Format
- 720p
- Output Scan Format
- 480p
- Audio
- Number of Speakers
- 1
- Speaker Output Power
- 15 W
- Speaker Output Mode
- Stereo
- Speaker Included
- Yes
- Network & Communication
- Wireless LAN
- Yes
- Wireless LAN Standard
- IEEE 802.11ac
- Wireless LAN Standard Detail
- 802.11 a/b/g/n/ac (2.4G/5G), 1T1R (UWA5)
- Wireless Capability
- Miracast Wi-Fi
- EZCast
- Chromecast
- Interfaces/Ports
- HDMI
- Yes
- HDMI Version
- HDMI 2.0
- Number of HDMI Ports
- 2
- HDMI Detail
- HDMI (2.0) x 2
- Total Number of HDMI Ports
- 2
- Number of USB Ports
- 3
- USB
- Yes
- USB Connector Type
- 3 x Type-A
- USB Detail
- DC Out (5V/1.5A, USB Type A) x 1;USB (Type A) x 1, for WiFi Dongle;USB (Type A) x 1, share output port
- VGA In
- Yes
- Number of VGA Inputs
- 1
- Number Of Audio Inputs
- 1
- Audio Line In
- Yes
- Number Of Audio Outputs
- 1
- Audio Line Out
- Yes
- RS-232 (D-sub)
- 1
- USB Type-A Out
- x1, DC Out (5V/1.5A)
- Power Description
- Input Voltage
- 120 V AC
- 230 V AC
- Input Voltage Range
- 120 V AC - 230 V AC
- Operating Power Consumption
- 210 W
- Standby Power Consumption
- 500 mW
- Power Supply
- 100 V AC ~ 240 V AC
- Power Supply Input Voltage Range
- AC input 100~240V
- Physical Characteristics
- Form Factor
- Ceiling Mountable
- Height
- 115.5 mm
- Width
- 337 mm
- Depth
- 216 mm
- Weight (Approximate)
- 2.90 kg
- Operating Temperature
- 0°C to 40°C
- Operating Humidity
- 80%
- Installation
- Ceiling Mount
- Security
- Security Bar
- Kensington Lock
- Miscellaneous
- Package Contents
- Vero PL2535i DLP Projector
- AC Power Cord
- AC to DC Power Adapter
- Battery for remote control
- HDMI Cable
- Lens Cap
- Quick Start Guide
- Remote Control
- Carrying Case
- Country of Origin
- China
- Standard Accessories
- AC Power Cord
- AC to DC Power Adapter
- Battery for remote control
- HDMI Cable
- Lens Cap
- Quick Start Guide
- Remote Control
- Carrying Case
