- General Information
- Manufacturer
- Dell Technologies
- Manufacturer Website Address
- http://www.dell.co.uk
- Brand Name
- Dell
- Product Line
- Pro Dock
- Marketing Information
Fuel your productivity
Gain the versatility to create your ideal workspace with a dock featuring 6 USB ports, support for 4 displays and driving up to 100W of power delivery to the latest Dell AI PCs for optimal productivity.
More manageable
Keep your dock up to date and work without interruption.
Improved manageability
Manage your dock from the Dell Device Management Console by utilising Dell Display and Peripheral Manager installed on your PC.
Simplify firmware updates
Reduce IT complexity by deploying a single firmware file across workspaces.
Minimise end-user disruption with silent firmware updates that are executed upon dock disconnection.
Work with confidence
Enhance your docking experience with universally compatible features including MAC Address Pass-Through and Power Button Sync, for a better docking experience across brands.
Connect your way
Configure your workspace to your liking with an ambidextrous USB-C cable that can be routed left or right.
Designed for sustainability
The Dell Pro Dock is built with at least 65% post-consumer recycled materials and packaged with 100% recycled or renewable packaging, and offering up to 72% power consumption reduction on standby mode.
- Product Type
- Docking Station
- Technical Information
- Connectivity Technology
- Wired
- Device Supported
- Notebook
- Monitor
- Desktop PC
- Cable Length
- 80 cm
- Features
- Power Delivery Pass-through
- Management Features
- MAC Address Pass-through
- PXE Boot
- Wake-on-LAN
- WLAN to LAN Switch
- Kernel Direct Memory Access (DMA) Protection
- Port Disablement
- Firmware update on disconnect
- Host PC based firmware update
- Dock Power Button Sync
- Number of Displays Supported
- 4
- Screen Mode Supported
- WQHD @ 60Hz
- 5K @ 60Hz
- 6K @ 60Hz
- HD @ 60Hz
- FHD @ 60Hz
- QHD @ 60Hz
- 4K @ 60Hz
- Supported Resolutions
- 3440 x 1440
- 5120 x 2160
- 6144 x 3456
- 1280 x 720
- 1920 x 1080
- 2560 x 1440
- 3840 x 2160
- Maximum Data Transfer Rate
- 1.25 GB/s
- Security Slot Type
- Kensington Security Slot
- Power Delivery Details
- 4 x USB-A 3.2 Gen 2 (4.5W each)
- 1 x USB-C 3.2 Gen 2 (15 W)
- 1 x USB-C Multifunction DisplayPort (7.5W)
- All of them supply electricity, with or without a PC.
- 100W (Dell systems)
- 96W (non-Dell systems)
- Power Delivery
- 100W (Dell Systems)
- 96W (non-Dell Systems)
- Video Resolution Details
- WQHD - 60 Hz (Quad Display)
- WQHD - 60 Hz (Triple Display)
- 5K - 60 Hz (Dual Display)
- 6K - 60 Hz (Single Display)
- HD - 60 Hz (Quad Display)
- FHD - 60 Hz (Triple Display)
- QHD - 60 Hz (Dual Display)
- 4K - 60 Hz (Single Display)
- Network & Communication
- Ethernet Technology
- 2.5 Gigabit Ethernet
- Interfaces/Ports
- Host Interface
- USB Type C
- Total Number of USB Ports
- 6
- USB Type-A
- Yes
- Number of USB 3.2 Gen 2 Type-A Ports
- 4
- Number of USB 3.2 Gen 2 Type-C Ports
- 2
- Number of USB Type-A Ports
- 4
- USB Type-C
- Yes
- USB Type-C Detail
- 1 x USB-C 3.2 Gen 2 (10Gbps)
- Number of USB Type-C Ports
- 2
- Network (RJ-45)
- Yes
- DisplayPort
- Yes
- Number of DisplayPorts
- 2
- DisplayPort Version
- 1.4
- HDMI
- Yes
- Number of HDMI Ports
- 1
- HDMI Version
HDMI 2.1
- Total Number of Ports
- 10
- Software
- Operating System Supported
- Windows 10
- Windows 11
- Ubuntu
- Red Hat Enterprise Linux
- ChromeOS
- Power Description
- Maximum Power Supply Wattage
- 130 W
- Power Source Type
- Power Supply
- Physical Characteristics
- Height
- 205 mm
- Width
- 90 mm
- Depth
- 35.3 mm
- Weight (Approximate)
- 550 g
- Miscellaneous
- Package Contents
- Pro Dock WD25 Docking Station
- Power Adapter and Power Cable
- Documentation (quick guide, safety, environmental and regulatory information)
- Kensington Security Slot
- Yes
- Compatibility
Dell Products:
- Pro PC14250
- Pro PC14255
- Pro PC16250
- Pro PC16255
- Pro Plus PB13250
- Pro Plus PB13255
- Pro Plus PB14250
- Pro Plus PB14255
- Pro Plus PB16250
- Pro Plus PB16255
- Pro Premium PA13250
- Pro Premium PA14250
- Pro Rugged 10 Tablet RA00260
- Pro Rugged 12 Tablet RA02260
- Pro Rugged 13 RA13250
- Pro Rugged 14 RB14250
- Inspiron 5441
- Inspiron 5640
- Inspiron 5645
- Inspiron 7441
- Latitude 3330
- Latitude 3340
- Latitude 3430
- Latitude 3440
- Latitude 3445 Chrome
- Latitude 3450
- Latitude 3530
- Latitude 3540
- Latitude 3550
- Latitude 5330
- Latitude 5330 2-in-1
- Latitude 5340
- Latitude 5340 2-in-1
- Latitude 5350 (Laptop or 2-in-1)
- Latitude 5430
- Latitude 5430 Chromebook Enterprise
- Latitude 5431
- Latitude 5440
https://www.dell.com/de-de/shop/dell-pro-dock-wd25/apd/210-brfq/docks-and-stands
- Post-consumer-waste%
- 65%
