- General Information
- Manufacturer
- Hikvision
- Manufacturer Website Address
- http://www.hikvision.com
- Brand Name
- Hikvision
- Product Series
- Pro
- Product Type
- Network Camera
- Technical Information
- HD Recording
- Yes
- Night Vision
- Yes
- Night Vision Distance
- 8 m
- Night Vision Type
- Infrared
- Camera Iris
- Fixed
- Display & Graphics
- Image Sensor Type
- CMOS
- Image Sensor Size
- 1/2.7"
- Colour Supported
- Colour
- Field of View
- horizontal FOV: 180°, vertical FOV: 180°, diagonal FOV: 180°
- Effective Camera Resolution
- 5 Megapixel
- Video
- Video Formats
- H.265
- H.264
- H.264+
- H.265+
- MJPEG
- H.264M
- H.264H
- H.265M
- H.264B
- Maximum Video Resolution
- 2560 x 1920
- Maximum Frame Rate
- 30 fps
- Lens
- Lens Type
- Fixed
- Maximum Focal Length
- 1.05 mm
- Lens Included
- Yes
- Lens Mount Type
- M12-mount
- Maximum Aperture
- f/2.25
- Exposure
- Shortest Shutter Speed
- 1/100000 Second
- Longest Shutter Speed
- 1/3 Second
- Network & Communication
- Connectivity Technology
- Wired
- Ethernet Technology
- Fast Ethernet
- Protocols
- TCP/IP
- ICMP
- HTTP
- HTTPS
- FTP
- DHCP
- DNS
- DDNS
- RTP
- RTSP
- RTCP
- PPPoE
- NTP
- UPnP
- SMTP
- SNMP
- IGMP
- 802.1X
- QoS
- IPv6
- Bonjour
- IPv4
- UDP
- SSL/TLS
- Remote Management
- Yes
- Storage
- Storage Type
- Memory Card
- Interfaces/Ports
- Network (RJ-45)
- Yes
- Power Description
- Maximum Power Consumption
- 7.50 W
- Input Voltage
- 12 V DC
- Power Source Type
- PoE
- DC
- Physical Characteristics
- Mount Type
- Table Mount
- Ceiling Mount
- Form Factor
- Fisheye
- Diameter
- 119.9 mm
- Weight (Approximate)
- 320 g
- Environmental Conditions
- Minimum Operating Temperature
- -10°C
- Maximum Operating Temperature
- 50°C
- Maximum Operating Humidity
- 95%
- Miscellaneous
- Features
- Wide Dynamic Range
- Back Light Compensation (BLC)
- 3D Digital Noise Reduction
- Audio Compression
- Region of Interest
- Day/Night
- Motion Detection
- Password Protection
- Built-in Microphone
- Tampering Alarm
- Environmentally Friendly
- Yes
- Environmental Compliance
- Restriction of Hazardous Substances (RoHS)
